BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD

BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD

  • BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
  • BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
  • BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
  • BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
  • BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
  • BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD
Produktdetails:
Herkunftsort: Jiangsu, China
Markenname: SUMA or OEM
Modellnummer: BB 25-2K-K
Zahlung und Versand AGB:
Min Bestellmenge: 2
Preis: $6.30-6.80
Kontakt
Ausführliche Produkt-Beschreibung
Typ: BB-Reihe Präzisionsbewertung: P0, P6
Versiegelungsart: Versiegelt Material: GCR15
Außendurchmesser: 52 mm Bohrungsgröße: 25 mm
Drehmomentkapazität: 78 nm Max Überaufnahme (innere): 2500 R/Min
Maximalübergreifend (äußere): 1400 r/min Schleppmoment: 0,017 n*m
Betriebstemperatur: -30°C zu +100°C Gewicht: 150 N
Lagerlast (Cr): 10700 n Lagerlast (Kor): 6300 n
Keyway -Abmessungen: 8x5x15 (innere), 6x4x15 (äußere)
Hervorheben:

25mm one way clutch bearing

,

52mm OD clutch bearing

,

BB Series one way bearing

One Way Clutch Bearing BB 25-2K-K Cam Clutch Industrial Bearing
Product Specifications
Attribute Value
Applicable Industries Garment Shops, Machinery Repair Shops, Food & Beverage Factory, Construction works, Energy & Mining, Other
Type BB Series
Precision Rating P0, P6
Seals Type Sealed
Material GCr15
Outer diameter 52 mm
Bore size 25 mm
Torque Capacity 78 Nm
Package Single box or as your requirements
Port Shanghai, Ningbo
Size Standard Size
Delivery time 10-15 Days
OEM Accept
Product Overview
The BB Series One Way Clutch Bearing BB 25-2K-K is a high-performance cam clutch industrial bearing designed for demanding applications across various industries. This precision-engineered component features keyways on both inner and outer races for secure installation.
BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 0
Technical Specifications
Item BB 2K-K
Material GCr15
Outer diameter 52 mm
Bore size 25 mm
Torque Capacity 78 Nm
Max. Overrunning (inner race) 2500 r/min
Max. Overrunning (outer race) 1400 r/min
Port Shanghai; Ningbo
Delivery time 10-15 days
Installation & Usage Features
  • Designed for press fit installation with keyways on both inner and outer races
  • Includes keys shipped together with Cam Clutch ("-K" designation)
  • Maintain correct interference dimensions at shaft and housing for optimal performance
  • Dust seal protection against particles of 0.25mm and over
  • Arrow on inner race indicates direction of engagement
  • Use appropriate press tool for installation - do not hammer or apply shock
  • Operating temperature range: -30°C to +100°C
  • Housing must have sufficient strength to withstand press fitting pressure
BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 1 BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 2
Dimensions and Capacities
Comprehensive dimensional data and load capacities available in the technical specifications table. All models are dimensionally interchangeable with competitors.
Tolerance Specifications
Detailed shaft and housing tolerance requirements are provided for precise installation and optimal performance.
Lubrication Guidelines
  • Pre-greased before delivery - no additional lubrication required before use
  • For oil lubrication systems, ensure continuous internal oil application
  • Do not use greases or lubricants with EP additives
BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 3 BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 4 BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 5 BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 6 BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 7
Manufacturer Information
Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) specializes in manufacturing high-quality cam clutches, one way bearings, and industrial clutch solutions. Our commitment to "Best Quality, Best Price, Fast Delivery, Best Service" ensures customer satisfaction.
Quality Assurance
  • Advanced production equipment
  • Strict raw material requirements
  • Complete and perfected process flow
  • Consistent quality control for every batch
  • Competitive pricing for different quality grades
Customer Support
Pre-sale service: Delivery within 10 days after order confirmation
After-sale service: Technical assistance for usage and maintenance
BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 8 BB Series One Way Clutch Bearing BB 25-2K-K 25mm Bore 52mm OD 9
Frequently Asked Questions
Q: Why choose your company?
A: We maintain strict quality control with our own bearing factory, offering competitive pricing for premium one way clutch bearings.
Q: What is the delivery time?
A: Most bearings are in stock. Small quantities ship within 15 days.
Q: What payment methods do you accept?
A: We accept L/C, T/T, Western Union, Paypal and other payment methods.
Q: Can you send samples first?
A: Yes, we can provide samples for quality verification before bulk orders.
Contact us anytime for your industrial bearing and clutch requirements.
